Factory Manufacture Perforating Rewinder Toilet Paper Machinery Tissue Paper Roll Slitting Rewinding Machine
Basic Info
| Model NO. | Toilet Paper rewinding machine-9 |
| Certification | CE, ISO 9001:2008 |
| Condition | New |
| Control | Automatic |
| Embossing Type | Full-Embossing |
| Embossing Roller | Rubber Roller |
| Toilet Paper Type | Without Core |
| Function | Rewinder |
| Achine Type Sf-Dyy 1575(Can Increase Th | 5.5kw |
| Jumbo Roll Stand | 1-3 Ply (Set by Per Customer). |
| Name | Tissue Paper Roll Slitting Rewinding Machine |
| Base Paper Diameter | ≤1100mm(Other Sizes Please Specify) |
| Color | Optional Color |
| Base Paper Paper Core Diameter | 15-76.2mm(Other Sizes Please Specify) |
| Programmable Controller | PLC |
| Working Speed | 150-200 M/Min. |
| Diameter of Finished Products | 60-150mm(Tightness Can Be Adjusted) |
| Perforating Distance | 100-150mm (It Can Be Adjusted) |
| Transport Package | Standard Export Wooden Box Packaging |
| Specification | Depends |
| Trademark | Shunfu |
| Origin | China |
Product Description
Factory Manufacture Perforating Rewinder Toilet Paper Machinery Tissue Paper Roll Slitting Rewinding Machine
Descripton of Toilet Paper Roll Rewinding Machine
Dot-by-dot rewinding and perforated gluing towel paper machine , this machine is to emboss on tow lays paper , glue ,combine , perforate ,rewind and cut into various kind of specifications of towel rolls according to the requested.Glue on finished product which produced by this machine is equal, and the tension of rewind is uniformity.This machine has the feature of compact structure, steady production ,simple and convenient operation, less electricity consumption and covers a small area of 8.4 m² , The highest speed is 30-100M/min. This is the idea equipment for paper processing factory. This equipment can process raw paper of 1.2m 1.75m 1.95m 2.15m 2.35m 2.55m in width. This machine is consist of stand of raw material, paper conveying unit, embossing unit, gluing unit ,perforating unit, rolling unit, electricity control and cutting system.
The production process is : unreeling -→ embossing -→ gluing-→perforating -→ reeling-→cut.
Technical Parameter of Toilet Paper Roll Rewinding Machine
| Achine type | SF-DYY 1575(Can increase the type) |
| Width of raw material paper | ≤1800mm(Can widen) |
| Base paper diameter | ≤1100mm(Other sizes please specify) |
| Base paper paper core diameter | Φ15-76.2mm(Other sizes please specify) |
| Programmable controller | PLC |
| Production speed | 150-200 m/min |
| Machine power | 5.5KW |
| Voltage | 380V,50Hz |
| Diameter of finished products | 60-150mm(tightness can be adjusted) |
| Perforating distance | 100-150mm (it can be adjusted) |
| Embossing unit(Need to be customized) | steel roller to rubber roller/paper roller/steel roller(set by per customer) Remark:Purchased separately |
| Jumbo roll stand | 1-3 ply (set by per customer) |
| Overall size | 5.5x2.7x1.5m(LxWxH) |
| Weight | 2.5T |
| Other models(Prices are negotiable) | |
| Type | Width of raw material paper |
| SF-DYY 1760 | ≤2000mm |
| SF-DYY 1880 | ≤2200mm |
| SF-DYY 2100 | ≤2400mm |
| SF-DYY 2400 | ≤2600mm |
Charactors of Toilet Paper Roll Rewinding Machine
1,Automatic paper tube replacement device , without artificial wearing paper tube , after the completion of rewinding automatically send finished , immediately reset rewinding within one minute can be adjusted to any kind of standard paper tube ;2,Sent automatically after rewinding molding system that uses robotic arm pusher patented technology can successfully send the finished product , the minimum diameter of the finished product launch 60mm;3,Automatic trimming, gluing , sealing sync once completed, the device instead of the traditional waterline trimming to achieve foreign popular sticky tail trimming techniques , finished leaving the tail 10 ~ 18mm , easy to enable , to reduce the general Winder when the tail of the loss making machine , thereby reducing the product ;4,The use of advanced PLC programming technology , product realization process in rewinding loose multistage different tightness after the first tight resolve the finished result from long-term storage of loose paper core phenomenon.
Related product processOur ServiceCompany Information
If you have any questions, please free to contact me
